Researchers at the National University of Singapore (NUS) have developed a stretchable, self-healing and illuminating material for uses including robotic smart farming, space exploration and search and rescue missions.
The new stretchable material, when used in light-emitting capacitor devices, is claimed to enable highly visible illumination at much lower operating voltages and is also resilient to damage due to its self-healing properties.
The HELIOS (Healable, Low-field Illuminating Optoelectronic Stretchable) device was created by Assistant Professor Benjamin Tee and his team from the NUS’s Institute for Health Innovation & Technology and the Department of Materials Science and Engineering at the NUS Faculty of Engineering. The results have been reported in Nature Materials.
“Conventional stretchable optoelectronic materials require high voltage and high frequencies to achieve visible brightness, which limit portability and operating lifetimes. Such materials are also difficult to apply safely and quietly on human-machine interfaces,” said Asst Prof Tee.
To overcome these challenges, the team of NUS researchers began studying and experimenting with possible solutions in 2018, and eventually developed HELIOS after a year.
To lower the electronic operating conditions of stretchable optoelectronic materials, the team developed a material that has very high dielectric permittivity and self-healing properties. The material is a transparent, elastic rubber sheet made up of a blend of fluoroelastomer and surfactant.
According to NUS, the high dielectric permittivity enables it to store more electronic charges at lower voltages, enabling a higher brightness when used in a light-emitting capacitor device.
Unlike existing stretchable light-emitting capacitors, HELIOS enabled devices can turn on at voltages that are four times lower and achieve illumination that is more than 20 times brighter.
It also achieved an illumination of 1460 cd/m2 at 2.5 V/µm, the brightest attained by stretchable light-emitting capacitors to date and is now comparable to the brightness of mobile phone screens.
Due to the low power consumption, HELIOS can achieve a longer operating lifetime, be utilised safely in human-machine interfaces, and be powered wirelessly to improve portability.
HELIOS is also claimed to be resistant to tears and punctures. The reversible bonds between the molecules of the material can be broken and reformed, which allows the material to self-heal under ambient environmental conditions.
Asst Prof Tee said: “Light is an essential mode of communication between humans and machines.
“As humans become increasingly dependent on machines and robots, there is huge value in using HELIOS to create ‘invincible’ light-emitting devices or displays that are not only durable but also energy-efficient.
“This could generate long-term cost savings for manufacturers and consumers, reduce electronic waste and energy consumption, and in turn, enable advanced display technologies to become both wallet and environmentally friendly.”
The team believes HELIOS can be used to fabricate long-lasting wireless displays that are damage-proof.
It can also function as an illuminating electronic skin for autonomous soft robots to be deployed for smart indoor farming, space missions or disaster zones.
Having a low-power, self-repairing illuminating skin will provide safety lighting for robots to manoeuvre in the dark while remaining operational for prolonged periods.
The NUS team has filed for a patent for the new material and is looking to scale up the technology for specialty packaging, safety lights, wearable devices, automotive and robotics applications.
